Bubble (Water / Air) Washer

Our bubble washer can be used for a variety of fruits and vegetables, including leafy greens. A combination of soaking, air agitation, debris removal and final rinse are applied. In the end, your products are handled gently, and come out clean and safe.

Product Description

Our bubble (water / air) washer, is a very popular model.  It can be used for a variety of fruits and vegetables, including leafy greens / head lettuce.  A combination of soaking, air agitation, debris removal and final rinse are applied – creating the water air washer process. In the end, your products are handled gently, and come out clean and safe.

For sandy / heavily soiled products, see our jet washer.

Products

  • Fruits that Float
    • Cherries
    • Berries (non-fragile)
    • Plums
  • Lettuce
    • Heads
    • Hearts
  • Leafy Greens
    • Baby Greens
    • Chickory / Radicchio
    • Kale
    • Microgreens
    • Molokhia
    • Salads & Mixes
    • Spinach
  • Vegetables
    • Broccoli / Cauliflower (florettes)
    • Cucumbers
    • Eggplant
    • Leeks
    • Mushrooms (button / white / champignons)
    • Onions
    • Rhubarb
    • Zucchini

Operational Process

Incoming product is fed into the bubble washer water tank. High-powered air introduced to the tank produces bubbling agitation. This agitation gently removes debris and contaminants. Additional air nozzles progress the cleaned product towards the rear of the unit. Here, optional paddles submerge the product one last time to remove any leftover debris. A second paddle removes floating impurities.  Next, the drip conveyor collects the product from the tank. A final spray nozzle above the conveyor rinses the product one last time. Finally, product is discharged.

Safety & Sustainability

This bubble washer is a closed system to capture water. Options to reuse the water further reduce your consumption and waste.

Features
  • Efficient and powerful, yet gentle, cleaning
  • Low power consumption
  • Closed water cleaning and reusability system
  • Lift conveyor with a modular belt
  • Fresh water rinse system
  • Stone catcher
  • Waste and impurity discharge valves
  • Water level sensor
  • Control system
Options
  • Tumbler drum (in tank)
  • Water recycling system
  • Floating impurities removal system
  • Automatic water regulation system
  • Automated waste discharge upgrade, with sensors



Capacityup to 3 tons/hr, depending on product and contamination levels
Width (overall)1 705 mm
Width of the working surface1000 mm
Height1 640 mm
Length5 380 mm
In-feed height950 mm (±50 mm)
In-feed width1 000 mm
Power400 V, 50 Hz
Drive motion motors0.75 kW
Drive ventilator1.5 kW
Drive water pump3.5 kW
  • Main working trough
  • Bottom tank of cleaned water
  • High power side channel fan that discharges air into the main trough
  • Lift conveyor with the modular belt
  • Efficient cleaning system of process water on the chute sieve
  • Product immersion drum
  • Floating impurities removal system
  • Stone catcher located in the bottom sieve of the trough
  • Lances rinsing with fresh water – 2 pcs.
  • Drain valves for discharge of impurities
  • Control cabinet with control systems
  • Safety housings and guard
